Stable brushless motor intelligent common Tripod turnstile CXT-SW128YX| Model | CXT-SW128YX |
| Specifications | 1200*280*980 |
| Rod length | 510mm |
| Process | Produced by bending, cutting, welding, polishing, grinding and other processes |
| Material | National standard 304 stainless steel (201 stainless steel, iron paint can be customized) |
CXT-SW128YX smart inclined three-roller turnstile
1) It has fault self-checking and alarm prompt functions, which is convenient for users to maintain and use.
2) It can be connected to any control signal or button or remote control output by any control device to realize single-way and two-way control passage.
3) It can arbitrarily set single-way and two-way free passage.
4) Automatic reset function: It will automatically reset every time it rotates 120 degrees, or if it does not pass within the specified time (delay is adjustable in multiple gears), the system will automatically cancel the right to pass this time.
5) Light indication: High-brightness traffic light status indication, guiding passage.
6) Anti-tailing function: It rotates 120 degrees for each person passing. If someone follows the gate, it will automatically lock and alarm.
7) Fire input: It can be connected to the fire alarm signal to realize the uninterrupted power-off and normal opening of the gate.
8) Memory function: Accurate signal memory, when receiving legal signals for multiple consecutive times, it will automatically reset after detecting the last person passing, which greatly improves the passage speed. (This function can be selected by dialing)
9) Alarm prompt function: When passing illegally or rushing through the gate, an alarm prompt will be automatically issued.
10) Anti-reversal function: When reversal occurs during the passage, the gate bar will automatically lock and issue an alarm, and the passage will be automatically restored after the reversal external force disappears.
11) Anti-buffer function: When passing illegally or rushing through the gate, the gate bar will automatically rotate to the corresponding angle and lock to achieve humanized injury prevention. When the external force disappears, it will automatically reset.
12) Unattended: The gate bar will automatically drop when the power is off, and automatically go up when the power is on.
13) Dynamic prompt: When receiving a legal passage signal, the gate bar will automatically rotate about 5 degrees, and it will gently rotate to the next reset point and stop after a light touch.
Tripod turnstile can be expanded:
1. Remote control and management through the management computer (command docking is required).
2. Counting function to realize the number of people present.
3. Personalized voice prompt function makes the channel closer to life.
| No | Name | Common series on the market | Pentium series |
| 1 | Rotation mode | push | electric |
| 2 | Positioning principle | optical coupling fixed point | 1/500 decoding, |
| 3 | Positioning mode positioning arm | horizontal position | not locked |
| 4 | Transmission mode | solenoid valve | motor |
| 5 | Lifting rod mode | manual | automatic |
| 6 | Buffer | no | yes |
| 7 | Anti-reverse | no | yes |
| 8 | Noise | high | no |
| 9 | Mechanical wear | high | no |
| 10 | Illegal alarm | no | yes |
| 11 | Passage prompt | no | yes |
| 12 | Service life | 1-3 years | 5-10 years |
| 13 | Door rod thickness | ￠32 | ￠38 |
| 14 | Power off drop | yes | yes |
| 15 | Memory | yes | yes |
| 16 | Fire input | yes | yes |
| 17 | Feedback signal output | yes | yes |
FAQ:
1.Will you install the channel lock for the first time?
Answer: on channel brake installation is very simple, just put the product fixed well, main machine and insert 110V/220V power supply, can normal use, if you need to connected to the Internet, only need to use a network line can be received from the main computer, we will provide all the one-on-one phone technology Guidance services.
2.Can machines be used outside?
Answer:It can be used outside. We all have waterproof function.
3.What is the warranty for the machine?
Answer: (1) we guarantee all goods quality assurance for two years.
(2) within the two years warranty time,if the machine have problem,we can offer you the accessories(but you pay the freight cost)
4.When will you make the delivery?
Answer:regular products
3-5 days),irregular products:communication when you place the order.
